PEEK Rod
Overview :
About PEEK semi-finished products, in addition to unfilled PEEK, a red pigmented version of PEEK is also available in rod, and plate, in a variety of dimensions. This red pigmented version of PEEK plastic has the same properties as unfilled PEEK material, such as excellent resistance to high temperatures, high dimensional stability, excellent chemical resistance and so on. In addition to red, PEEK rod and PEEK plate can also be other colors as your demands, such as yellow, blue, black, and so on.
General Dimensions of PEEK Rod
| DIAMETER (mm) | LENGTH (mm) | TOLERANCE MAX (mm) | WEIGHT (KG/M) |
| 6 | 1000 | +2 | 0.07 |
| 8 | 1000 | +2 | 0.10 |
| 10 | 1000 | +2 | 0.15 |
| 15 | 1000 | +2 | 0.30 |
| 20 | 1000 | +2 | 0.50 |
| 25 | 1000 | +2 | 0.75 |
| 30 | 1000 | +2 | 1.05 |
| 35 | 1000 | +2 | 1.41 |
| 40 | 1000 | +2 | 1.82 |
| 45 | 1000 | +2 | 2.27 |
| 50 | 1000 | +2 | 2.78 |
| 60 | 1000 | +2 | 3.95 |
| 70 | 1000 | +2 | 5.33 |
| 80 | 1000 | +2 | 6.91 |
| 90 | 1000 | +2 | 8.70 |
| 100 | 1000 | +2 | 10.70 |
| 150 | 1000 | +2 | 23.76 |
| 200 | 1000 | +2 | 41.96 |
Please contact us and ask for special dimensions.
Typical Application
Automobile Industry
Aerospace
Household Appliance
FAQ：
Whether to provide the sample and the delivery time of the sample ?
We can provide a sample of 3kg in stock within 5 working days.
Q1
Can you provide customized services?
Yes, all our raw materials can be customized, such as adding glass fiber, carbon fiber and other fillers, or making boards and rods of different sizes. Click for details to learn more>>
Can you provide the quality certificate of the products?
Of course. All of our products are proven to be perfectly compliant with FDA, REACH and RoHS safety regulatory, and so on. If you need, you can contact us to check the relevant documents.
Q3
Are you manufacturer or trading company?
We are integral part of industry and trade. Both the agency of some products, but also a factory for product development and production.
Q4
About bulk order leading time?
It will take about 15~30 working days from order confirmation to production completion. Specific communication can be coordinated to the time acceptable to both side.
Q5
